Made in the USA
 |
|
The Model HP-1 is a simple, low pressure, reliable, & light weight power supply, that delivers plenty of fluid power to operate BMF torque wrenches up to 10,000 Ft-LBS. Operation is very simple! Just turn the unit on and dial in the desired torque. The man handling the wrench then controls its operation by a valve on the wrench. A Separate electrical control pendant line is NOT used. If faster make-up is desired, choose the Model HP-1V to double the wrench speed over the Model HP-1 power supply.
|
 |
|
Model No
|
Standard Motor
|
Output
|
Reservoir
|
Dimensions
|
Weight
|
| HP-1 | 1-HP, 115 VAC, 60 HZ 1PH | 0.5 GPM | 1.5 GAL | 23" X 9" 13" | 54 LBS |
| HP-1A* | 1.5-HP, 40 SCFM @ 80 PSI (air) | 0.5 GPM | 1.5 GAL | 18" X 9" 13" | 45 LBS |
| HP-1U | 1.5-HP, 115 VAC, 60 HZ 3PH | 0.8 GPM | 1.5 GAL | 23" X 9" 13" | 65 LBS |
| HP-1UV | 3-HP, 115 VAC, 60 HZ 3PH | 1.5 GPM | 1.5 GAL | 23" X 9" 13" | 65 LBS |
| HP-1V | 2-HP, 115 VAC, 60 HZ 1PH | 1.0 GPM | 1.5 GAL | 25" X 9" 13" | 65 LBS |
| HP-1Y | 1.5-HP, 220 VAC, 50 HZ 1PH | 0.8 GPM | 1.5 GAL | 23" X 8" 13" | 65 LBS |
* Air powered model. Includes air filter, regulator and lubricator.
